New 2027

MULE SX 4x4 XC LE

BUILT STRONG TO WORK HARD

Styled in the image of its full-size MULE PRO siblings, the MULE SX family of utility vehicles packs plenty of stout muscle into compact and agile 2-passenger side x sides. Handle a wide variety of tasks with the ability to tread lightly and maneuver in tight areas—and fit in the bed of a full-size pickup truck.

KEY FEATURES:

401 CC 4-STROKE ENGINE
CONTINUOUSLY VARIABLE TRANSMISSION (CVT) WITH (H, L, N, R)
COMPACT SIZE AND TIGHT TURNING RADIUS
STEEL CARGO BED WITH TEXTURED FLOOR
500 KG TOWING CAPACITY

Additional Features:

Fuel-injected engine
Selectable 2WD/4WD/dual-mode rear differential with diff. lock
12-inch cast aluminium wheels with 26-inch tyres
4 high-intensity LED headlights
Plastic roof and special graphics

Colour

Metallic Onyx Black

Edition of MULE SX 4x4 XC LE

Standard

Inpage Navigation Section: Gallery

Load more images

Show less images

Inpage Navigation Section: Features & Specs

Features
Technologies
Specifications

Compact Size

Overall width is 1,335 mm; length is 2,710 mm. Tread measures 1,055 mm (front) and 1,000 mm (rear). Wheelbase is 1,780 mm.

Tough, Rugged Styling

Pickup truck style front hood, front grill and headlamp design modelled after the PRO Series MULE flagship models give the MULE SX models a tougher, rugged image like their bigger brethren.

Cargo Bed & Towing Capacity

Cargo bed dimensions are 1,040 x 905 x 245 mm. Its square, flat design makes it easy to load from three sides. Cargo bed load capacity is 181 kg

Transmission

Belt-driven automatic transmission with a Hi-Lo dual-range transfer case gives the 4WD models excellent off-road riding capability. Two forward speeds to choose from lend flexibility when hill-climbing with a heavy load.

Ample Range

16-litre fuel tank gives the fuel-efficient MULEs ample operating range. Redesigned fuel tank filler hole makes refuelling much easier.

Increased Comfort

Idealised front and rear suspension settings offer the following benefits: - increased stability - improved suspension action, contributing to off-road bump absorption and ground following, as well as increased ride comfort - improved handling response, facilitating control

Parking Brake

Pulling the parking brake lever (conveniently located to the left of the driver’s seat) operates a mechanical internal expansion type brakefor the rear wheels.

Tilt Steering

Steering wheel has a stepless adjustability range of approximately 29o, allowing drivers to set its position to suit their preference, as well as lift it out of the way to facilitate getting in and out of the vehicle

Simple, Reliable Engine

The MULE SX is powered by a 401 cm3, 4-stroke, OHV, air-cooled engine. Compact, lightweight and durable, the engine is extremely reliable.

Rugged Chassis

Highly durable ladder-type tubular steel frame designed for an ideal blend of rigidity and ride comfort.

Automotive Dashboard Design

Automotive-style dashboard designed based on that of the PRO Series models puts all controls within easy reach of the driver.

Storage

Removable front hood allows quick access to a spacious 60-litre sealed storage area. The hood releases are on the cab side, allowing access from inside the cab.
